Computer To Screen Exposing Machine CTS Imaging System UV405nm Laser 2540 Dpi

Computer-To-Screen Exposing Machine CTS Imaging Systems UV405nm Laser 2540 Dpi

CTS 300 Computer to screen based on DMD, Resolution:1270dpi or 2540dpi, with raster 133lpi/dpi(halftones printing) 3 minutes to finish the exposure on screen size 1100mm x 1250mm.

Computer-to-screen (CTS)

CTS is a computer-to-screen (CTS) imaging and exposure system (Chinese, Japanese, Korean, EU patent). Some rayon screens are exposed and imaged. It is also suitable for some graphics applications.

What is automatic expanding and shrinking?

In view of the special effect of printing paper with screen, traditional films need to be edited for printing down due to deformation after printing paper, resulting in manual work waste and precision loss. CTS300-AI uses CCD industrial camera to capture paper data, calculate paper deformation data through powerful computing ability while automatically expand and shrink the graph according to the paper deformation data, so that the graph on the screen accurately aligns the deformed paper, thereby eliminating the distress of editing film.

                                                                                                       *Specifications subject to change without notice

CTS Advantages

High Precision:

Resolutions 1270dpi or 2540dpi, with raster 133lpi/dpi (halftones printing)

High Efficiency:

3 minutes to finish the exposure on screen size 1000mm*1000mm. Stencil making efficieny has been greatly improved due to a lot of time is saved by the accurate exposure alignment and lobor reduction.

Low Cost:

Elimination of film positives. Litho film are becoming increasingly expensive and the number of suppliers on the maket is rapidly decreasing. 1 procedure of CTS digital screen making to replace 5 procedures of from the conventional process

High equipment quality:

The combination of GIS industrial-grade 405-nanometer coupled laser and our optical module is the only product on the market that can reach 50% laser usage, which can greatly save customers' use costs. Moreover, unlike expensive metal halide bulbs that need to be replaced every two years, CTS's laser light source can be used for 10,000 hours. The CTS computer-to-screen imaging and exposure system includes a computer, a monitor, and HQ RIP's proprietary software.
