| Brand Name: | GIS Laser |
| Model Number: | CTS1213V |
| Specifica�on / Model | Computer To Screen |
|---|---|
| Max screen size ( mm ) | 1200x1300 |
| Min screen size ( mm ) | N/A |
| Raster | Up To 100LPI |
| Equipment net weight | 1400KG |
| Conditions | Yellow Light Room With Cleanliness100000, Temperature 22±2°C, 40-70% Rela�ve Humidity (No Condensa�on) |
| Exposure time | 120-240s/㎡, #350 Yellow Mesh |
| Laser power | 20W/25W/30W(Optional) |
| Application | Textile, Decal, Label, Decoration, Packaging And PCB Etc. |
| Focus system | Auto Focusing |
| Equipment size (mm) | 2000x1157x2200 |
| Resolution | 1270dpi/2540dpi(Optional) |
Brand Name: GIS Laser
Model Number: CTS1213V
Place of Origin: Suzhou, China
Auto Focusing: 1_bit Tiff/ Gerber 274x
Max screen size (mm): 1100x1200mm
Laser power: 20W/25W/30W (Optional)
Exposure time: 120-240s/㎡, #350 Yellow Mesh
Laser type: UV Laser, Wavelength 405±5nm
The GIS Laser CTS1213V is a high-quality computer to screen (CTS) product that is designed to meet the needs of screen printing companies. With its advanced technology and precise laser beam, it is the perfect tool for creating screens with exceptional detail and accuracy.
The CTS1213V is ideal for a wide range of applications, including textile printing, graphic design, and label printing. It is suitable for creating screens for various materials such as cotton, polyester, and silk. Whether you are a small business owner or a large printing company, this product is perfect for all your screen printing needs.
The CTS1213V has a maximum exposure size of 1100x1200mm, which allows you to produce large screens without any loss of quality. This makes it an ideal choice for printing large designs or multiple designs on a single screen.
With laser power options of 20W, 25W, and 30W, the CTS1213V gives you the flexibility to choose the right power for your specific needs. The exposure time of 120-240s/㎡, combined with the #350 Yellow Mesh, ensures that your screens are exposed to the perfect amount of light, resulting in crisp and clean prints.
The CTS1213V uses an advanced UV laser with a wavelength of 405±5nm. This type of laser is known for its precision and efficiency, making it the perfect choice for creating screens with fine details and intricate designs.
The GIS Laser CTS1213V is a top-of-the-line product that offers exceptional quality, precision, and efficiency. Its advanced features, such as auto focusing and UV laser technology, make it a valuable asset for any screen printing business. So, if you want to take your screen printing to the next level, the CTS1213V is the perfect choice for you.
Brand Name: GIS Laser
Model Number: CTS1213V
Place of Origin: Suzhou, China
Emulsion thickness (EOM): Solvent Resistant Emulsion 3μm-150μm, Water Resistant Emulsion 3μm-350μm
Exposure time: 120-240s/㎡, #350 Yellow Mesh
Power: Single Phase 220V, 50/60HZ, 4KW, Compressor Air 0.5mpa
Laser power: 20W/25W/30W(Optional)
Equipment size (mm): 2000x1157x2200
The Computer To Screen (CTS1213V) is a top-of-the-line product from GIS Laser, a leading manufacturer of screen printing equipment. It is designed to provide high precision and efficiency for screen printing businesses.
The CTS1213V is compatible with screen frames of various thicknesses. It can handle frames with a thickness ranging from 3μm to 350μm, making it suitable for a wide range of screen printing needs.
With a maximum exposure size of 2000x1157mm, the CTS1213V allows for large format screen printing, making it ideal for printing on banners, posters, and other large materials.
Our Computer To Screen product comes in a sturdy and secure packaging to ensure safe delivery. The packaging is designed specifically to protect the product from any damage during shipping.
The packaging includes:
The product is carefully wrapped and sealed to prevent any scratches or dents. It is then placed in a durable cardboard box with additional padding for extra protection.
For international shipping, the product is securely packed in a wooden crate to withstand long distance travel and customs handling.
We use reliable and trusted shipping carriers to ensure timely delivery of our product. Our standard shipping time is 3-5 business days within the United States and 7-10 business days for international orders.
Upon shipment, a tracking number will be provided to the customer for easy tracking of their order.
At Computer To Screen, we value customer satisfaction and take every step to ensure that our product reaches you in perfect condition.
Thank you for choosing Computer To Screen!
