Jiangsu GIS Laser Technologies Inc., fannie.tian@gis-group.com.cn 86--13625276829
Product Details
Place of Origin: Jiangsu, China
Brand Name: GIS
Certification: ISO 9001
Model Number: CTS200C
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: negotiable price
Packaging Details: wooden case packing
Delivery Time: 20 work days
Supply Ability: 30set per month
Name: |
Computer To Screen |
Application: |
Decal Heat Transfer |
Resolution: |
1270dpi |
Max Screen: |
850x950 |
Raster: |
133LPI |
Equipment Size: |
2700*1550*1600mm |
Emulsion Thickness: |
3-350μm |
Laser Type: |
UV Laser Wavelength 405±5nm |
Equipment Net Weight: |
1200Kg |
Power: |
Single Phase, AC220v, 50/60HZ, 4KW, Compressed Air: 0.5mpa |
Name: |
Computer To Screen |
Application: |
Decal Heat Transfer |
Resolution: |
1270dpi |
Max Screen: |
850x950 |
Raster: |
133LPI |
Equipment Size: |
2700*1550*1600mm |
Emulsion Thickness: |
3-350μm |
Laser Type: |
UV Laser Wavelength 405±5nm |
Equipment Net Weight: |
1200Kg |
Power: |
Single Phase, AC220v, 50/60HZ, 4KW, Compressed Air: 0.5mpa |
GIS Tech Inc.
Jiangsu GIS technologies Inc.(hereinafter referred to as GIS)was founded in 2017. GIS have developed innovative technologies to launch CTS series products in the screen printing industry.
GIS aim: provide professional product solution and service, optimize and innovate customer manufacturing capabilities
GIS value: Innovation, Humility, Perseverance, Commitment
GIS is the pioneer in introducing the DLP technology into the laser imaging application. We own the whole independent intellectual properties in the technologies of data processing, data transmission, motion controller, laser module, optical lens etc.
Our main products: CTS (computer to screen) series.
Our products can be applied to textile, decal, package, glass, PCB industry.
|
Specification / Model |
CTS200C |
| Max screen size ( mm ) | 900x1000 |
| Min screen size ( mm ) | 400x400 |
|
Max exposure size ( mm ) |
850x950 |
| Screen frame thickness (bespoke service is available) |
25-45mm |
| Imaging System | DMD DLP Technology |
| Emulsion thickness (EOM) | Solvent resistant emulsion 3μm-150μm, water resistant emulsion 3μm- 350μm |
| Exposure time | 120-240s/ ㎡, #350 yellow mesh |
| Resolution | 1270dpi (Optional) |
| Raster | 133LPI |
| Focus system | Fixed focusing |
| File format | 1_bit tiff etc. |
| Laser type | UV laser, wavelength 405±5nm |
| Laser power | 20W/25W(Optional) |
| Equipment size (mm) | 2700*1550*1600mm |
| Equipment net weight | 1200KG |
| Conditions | Yellow light room with cleanliness Class 10000, temperature 22±2°C, 40-70% relative humidity (No condensation) |
| Power | Single phase 220v, 50/60HZ, 4KW, gas 1L/min |
