Solvent Resistant Emulsion 3μM-150μM UV Laser Cts Machine 400mm*500mm Min. Frame Size

Solvent Resistant Emulsion UV Laser 3μM-150μM 400mm*500mm Min. Frame Size 1500KG Net Weight

Product Description:

The Computer To Screen Exposing Machine is designed to provide a highly efficient and reliable solution to the demanding requirements of modern screen printing. With its outstanding features, such as water resistant emulsion 3μm-350μm, Exposure Time, high Resolution, DMD DLP Technology, 4KW, Compressor Air 0.5mpa, this machine is capable of producing a wide range of printed products with superior quality and accuracy. It has an emulsion thickness range of 3μm-150μm for solvent resistant emulsion and 3μm-350μm for water resistant emulsion. Its maximum exposure size is 850x950mm/ 33.5x37.4, and its resolution is 1270dpi. Moreover, the machine is powered by a single phase 220V, 50/60HZ, 4KW, Compressor Air 0.5mpa, making it highly energy efficient and reliable. The Computer To Screen Exposing Machine is the perfect solution for screen printing applications that require superior quality and accuracy.

Features:

• Product Name: Computer To Screen Exposing Machine
• Focus system: Auto Focusing
• Power: Single Phase 220V, 50/60HZ, 4KW, Compressor Air 0.5mpa
• Min. Frame Size: 400mm*500mm
• Conditions: Yellow Light Room With Cleanliness100000, Temperature 22±2°C, 40-70% Relative Humidity (No Condensation)
• Exposure time: 120-240s/㎡, #350 Yellow Mesh
• Solvent resistant emulsion 3μm-150μm
• DMD DLP Technology
• Auto Focusing

Technical Parameters:

Applications:

Customization:

Brand Name: GIS
Model Number: CTS910V
Place of Origin: Suzhou, China

Conditions: Yellow Light Room With Cleanliness100000, Temperature 22±2°C, 40-70% Relative Humidity (No Condensation)

Focus system: Auto Focusing
Laser type: UV Laser, Wavelength 405±5nm
Emulsion thickness (EOM): Solvent Resistant Emulsion 3μm-150μm, Water Resistant Emulsion 3μm-350μm
Application: Textile, Decal, Label, Decoration, Packaging And PCB Etc.

Max screen size: Up to 120 line, up to 120 line, 10.4 inch LCD

FAQ:

Q1: What is the Brand Name of the Computer To Screen Exposing Machine?

A1: The Brand Name of the Computer To Screen Exposing Machine is GIS.

Q2: What is the Model Number of the Computer To Screen Exposing Machine?

A2: The Model Number of the Computer To Screen Exposing Machine is CTS910V.

Q3: Where does the Computer To Screen Exposing Machine come from?

A3: The Computer To Screen Exposing Machine comes from Suzhou, China.

Q4: What kind of products can be printed using the Computer To Screen Exposing Machine?

A4: The Computer To Screen Exposing Machine can be used to print fabrics, garments, textiles, etc.

Q5: What are the advantages of using the Computer To Screen Exposing Machine?

A5: The Computer To Screen Exposing Machine offers high accuracy, high efficiency, shorter set-up time and improved print quality.
