20W/25W/30W DMD DLP Computer To Screen Exposing Machine With Auto Focusing Imaging System

20W/25W/30W DMD DLP Computer To Screen Exposing Machine With Auto Focusing Imaging System

Product Description:

Computer To Screen Exposing Machine is a high resolution, water resistant emulsion exposing solution with a resolution of up to 1270DPI. It is designed to handle the intricate details of the printing process for a variety of substrates with the thickness range between 3μm-350μm. It utilizes DMD DLP Technology and auto focusing system to ensure the highest accuracy and clarity possible. The machine is capable of handling 1-bit Tiff/Gerber 274x file format up to 100LPI raster.

Features:

• Product Name: Computer To Screen Exposing Machine
• File format: 1_bit Tiff/ Gerber 274x
• Min screen size ( mm ): 400x400mm/ 15.8x15.8
• Specificaon / Model: CTS 910V
• Exposure time: 120-240s/㎡, #350 Yellow Mesh
• Max screen size ( mm ): 900x1000mm/ 35.4x39.4
• Up to 120 lines
• Max screen size: 900x1000mm/ 35.4x39.4
• 1270DPI

Technical Parameters:

Applications:

Customization:

Computer To Screen Exposing Machine

Brand Name: GIS

Model Number: CTS910V

Place of Origin: Suzhou, China

Exposure time: 120-240s/㎡ #350 Yellow Mesh

Application: Textile, Decal, Label, Decoration, Packaging And PCB Etc.

Imaging System: DMD DLP Technology

File format: 1_bit Tiff/ Gerber 274x

Min. Frame Size: 400mm*500mm

Key Features: up to 120 line, water resistant emulsion 3μm-350μm

FAQ:

• Q: What brand is the Computer To Screen Exposing Machine? A: The Computer To Screen Exposing Machine is from GIS, the model number is CTS910V.
• Q: Where is the Computer To Screen Exposing Machine made? A: The Computer To Screen Exposing Machine is made in Suzhou, China.
• Q: What kind of applications can the Computer To Screen Exposing Machine complete? A: The Computer To Screen Exposing Machine can expose various kinds of films, such as the common positive films, negative films, aluminum films, polyester films, etc.
• Q: What advantages does the Computer To Screen Exposing Machine have? A: The Computer To Screen Exposing Machine has the advantages of fast exposure speed, high efficiency, stable performance, easy operation, and low cost.
• Q: What is the size of the Computer To Screen Exposing Machine? A: The size of the Computer To Screen Exposing Machine is 910*610mm.
