2540dpi CTS Computer To Screen 133LPI DMD DLP Technology

Name: 2540dpi CTS Computer To Screen 133LPI DMD DLP Technology
Brand: Jiangsu GIS Laser Technologies Inc.,
SKU: CTS100
Availability: InStock

Brand Name:	GIS
Model Number:	CTS100
MOQ:	1 set
Price:	negotiable price
Delivery Time:	20 work days

Detail Information

Product Description

Detail Information

Place of Origin:

Jiangsu, China

Certification:

ISO 9001

Name:

Computer To Screen

Application:

Textile

Resolution:

2540dpi

Max Screen:

900x1000

Emulsion Thickness:

3-350μm

Laser Type:

UV Laser Wavelength 405±5nm

Packaging Details:

wooden case packing

Supply Ability:

30set per month

Highlight:

2540dpi CTS Computer To Screen

Single Phase CTS Computer To Screen

220V uv exposure machine

Product Description

CTS laser direct plate making machine is to directly read computer data files and convert them into images, and then expose and image them on the screen by laser projection. This kind of imaging screen is suitable for textile printing, and also suitable for decals, packaging, PCB, 3C Printing on glass covers, etc.

Data files is directly read by the computer to screen (CTS) and then converted into images which will be transmitted through laser beams onto screens by DMD and lens.

The maximum screen frame size can reach 900x1000 (1080x1200 1200x1800 1500x2000 2000x3100 700x700) mm.

Specification / Model	CTS100
Max screen size ( mm )	900x1000
Min screen size ( mm )	400x400
Max exposure size ( mm )	800x900
Screen frame thickness (bespoke service is available)	25-45mm
Imaging System	DMD DLP Technology
Emulsion thickness (EOM)	Solvent resistant emulsion 3μm-150μm, water resistant emulsion 3μm- 220μm
Exposure time	120-240s/ ㎡, #350 yellow mesh
Resolution	1270/2540dpi (Optional)
Raster	133LPI
Focus system	Fixed focusing
File format	1_bit tiff etc.
Laser type	UV laser, wavelength 405±5nm
Laser power	20W/25W(Optional)
Equipment size (mm)	1550x1330x1460
Equipment net weight	1100KG
Conditions	Yellow light room with cleanliness Class 10000, temperature 22±2°C, 40-70% relative humidity (No condensation)
Power	Single phase 220v, 50/60HZ, 4KW(CTS200,CTS300), gas 1L/min

High Precision:

Resolutions 1270dpi or 2540dpi, with raster 133lpi/dpi (halftones printing).

High Efficiency:

3 minutes to finish the exposure on screen size 1000mm*1000mm. Stencil making efficieny has been greatly improved due to a lot of time

is saved by the accurate exposure alignment and lobor reduction.

Low Cost:

Elimination of film positives. Litho film are becoming increasingly expensive and the number of suppliers on the maket is rapidly

decreasing. 1 procedure of CTS digital screen making to replace 5 procedures of from the conventional process.
