1720dpi CTS Computer To Screen

1720dpi CTS Computer To Screen
1720dpi CTS Computer To Screen
1720dpi CTS Computer To Screen 1720dpi CTS Computer To Screen 1720dpi CTS Computer To Screen 1720dpi CTS Computer To Screen 1720dpi CTS Computer To Screen

Large Image :  1720dpi CTS Computer To Screen

Product Details:
Place of Origin: Jiangsu, China
Brand Name: GIS
Certification: ISO 9001
Model Number: CTS100
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable price
Packaging Details: wooden case packing
Delivery Time: 20 work days
Supply Ability: 30set per month

1720dpi CTS Computer To Screen

Description
Name: Computer To Screen Application: Textile
Resolution: 1270dpi Max Screen: 900x1000
Highlight:

1720dpi CTS Computer To Screen

,

1000mm CTS Computer To Screen

,

900mm computer to screen machine

CTS is a computer-to-screen (CTS) imaging and exposure system (Chinese, Japanese, Korean, EU patent). Some rayon screens are exposed and imaged. It is also suitable for some graphics applications.

The combination of GIS industrial-grade 405-nanometer coupled laser and our optical module is the only product on the market that can reach 50% laser usage, which can greatly save customers' use costs. Moreover, unlike expensive metal halide bulbs that need to be replaced every two years, CTS's laser light source can be used for 10,000 hours. The CTS computer-to-screen imaging and exposure system includes a computer, a monitor, and HQ RIP's proprietary software.

  •   Specification / Model

      CTS100
      Max screen size ( mm )   900x1000
      Min screen size ( mm )   400x400

      Max exposure size ( mm )

      800x900
      Screen frame thickness
      (bespoke service is available)
      25-45mm
      Imaging System   DMD DLP Technology
      Emulsion thickness (EOM)   Solvent resistant emulsion 3μm-150μm, water resistant emulsion 3μm-    220μm
      Exposure time   120-240s/ ㎡, #350 yellow mesh
      Resolution   1270/2540dpi (Optional)
      Raster   133LPI
      Focus system   Fixed focusing
      File format   1_bit tiff etc.
      Laser type   UV laser, wavelength 405±5nm
      Laser power   20W/25W(Optional)
      Equipment size (mm)   1550x1330x1460
      Equipment net weight   1100KG
      Conditions   Yellow light room with cleanliness Class 10000, temperature 22±2°C,
      40-70% relative humidity (No condensation)
      Power   Single phase 220v, 50/60HZ, 4KW(CTS200,CTS300), gas 1L/min
