Product Details
Place of Origin: Suzhou, China
Brand Name: GIS
Model Number: CTS1213V
Payment & Shipping Terms
Imaging System: |
DMD DLP Technology |
Resolution: |
1270dpi/2540dpi(Optional) |
Equipment Size (mm): |
2000x1157.5x2247mm/ 78.7x45.6x88.5" |
Equipment Net Weight: |
1450KG |
Exposure Time: |
120-240s/㎡, #350 Yellow Mesh |
Application: |
Textile, Decal, Label, Decoration, Packaging And PCB Etc. |
Focus System: |
Dynamic Focusing |
Min Screen Size ( Mm ): |
400x250mm/ 15.8x9.8" |
Imaging System: |
DMD DLP Technology |
Resolution: |
1270dpi/2540dpi(Optional) |
Equipment Size (mm): |
2000x1157.5x2247mm/ 78.7x45.6x88.5" |
Equipment Net Weight: |
1450KG |
Exposure Time: |
120-240s/㎡, #350 Yellow Mesh |
Application: |
Textile, Decal, Label, Decoration, Packaging And PCB Etc. |
Focus System: |
Dynamic Focusing |
Min Screen Size ( Mm ): |
400x250mm/ 15.8x9.8" |
CTS Computer To Screen is a direct to-screen imaging system designed to provide high resolution output at 133 LPI rastering. It is suitable for a wide variety of applications, and features a screen frame thickness of 20-50mm, with a bespoke service available to suit individual requirements. This system is suitable for yellow light rooms with cleanliness, maintaining a temperature of 22±2°C and a relative humidity of 40-70%, with no condensation. The CTS Computer To Screen is capable of accepting various file formats, including 1_bit Tiff, and is available with a laser power of either 20W/25W, providing the user with an optional choice. This system is lightweight, with an equipment net weight of just 1450KG.
Parameter | Value |
---|---|
Product Name | CTS Computer To Screen Direct Laser Image & Exposure machine |
Max Exposure Size (mm) | 1100(Height)x1200(length) |
Min Screen Size (mm) | 400x250mm/ 15.8x9.8" |
Conditions | Yellow Light Room With Cleanliness, Temperature 22±2°C, 40-70% Relative Humidity (No Condensation) |
Laser Power | 20W/25W (Optional) |
Equipment Size (mm) | 2000x1157.5x2247mm/ 78.7x45.6x88.5" |
Focus System | Dynamic Focusing |
Screen Frame Thickness | 20-50mm (bespoke Service Is Available) |
Emulsion Thickness (EOM) | Solvent Resistant Emulsion 3μm-150μm, Water Resistant Emulsion 3μm-350μm |
File Format | 1_bit Tiff Etc. |
Power | Single Phase 110V/ 220V, 50/60HZ, 4KW, Compressor Air 0.5mpa |
CTS Computer To Screen (GIS CTS1213V), made in Suzhou, China, is a direct to-screen imaging system designed for various applications including textile, decal, label, decoration, packaging and PCB. It utilizes 133 LPI raster with optional resolution of 1270 dpi or 2540 dpi, along with DMD DLP technology and dynamic focusing for laser power of 20W/25W. It has a perfect imaging quality of 2540dpi, which makes it the ideal choice for any production environment.
The system offers a perfect combination of DMD DLP technology and laser power of 20W/25W to ensure high accuracy and fast imaging. It also provides a reliable and stable imaging performance with its dynamic focusing technology. This makes it the perfect choice for any production environment.
CTS Computer To Screen (GIS CTS1213V) is the perfect solution for any production environment due to its superior imaging quality and high accuracy. Its 133 LPI raster, 2540 dpi resolution, DMD DLP technology and dynamic focusing make it the perfect choice for any production environment. It is the ideal solution for production needs of textile, decal, label, decoration, packaging and PCB.
The GIS CTS1213V Computer To Screen is a high resolution imaging system designed for screen printing on textiles. It is manufactured in Suzhou, China, and offers a minimum screen size of 400x250mm/ 15.8x9.8". It features Solvent Resistant Emulsion 3μm-150μm, Water Resistant Emulsion 3μm-350μm, DMD DLP Technology, and a net weight of 1450KG. It is designed to be used in yellow light room with cleanliness, temperature 22±2°C, and 40-70% relative humidity (no condensation).
CTS Computer To Screen is committed to providing customers with the best technical support and service. We offer a wide range of services to ensure that our customers have the best experience with our products. Our technical support team is available 24/7 to answer any questions you may have. We also provide regular updates and maintenance, as well as on-site installation and training. We strive to provide our customers with the best possible service and support to ensure that they are satisfied with our products.
CTS Computer to Screen products are shipped in a secure package to ensure safe arrival. The package consists of a custom Corrugated Cardboard Box, bubble wrap, and packing tape.
The box is designed to protect the product from damage during shipping. The bubble wrap provides additional cushioning to protect the product from shock. The packing tape is used to secure the box and keep it from opening during transit.
CTS Computer to Screen products are shipped via standard methods, such as USPS, UPS, or FedEx. Delivery time varies depending on the method of shipping chosen.
