Dynamic Focusing System Computer To Screen With Optional 20W/25W Laser Power

Dynamic Focusing System Computer To Screen With Optional 20W/25W Laser Power
Dynamic Focusing System Computer To Screen With Optional 20W/25W Laser Power Dynamic Focusing System Computer To Screen With Optional 20W/25W Laser Power Dynamic Focusing System Computer To Screen With Optional 20W/25W Laser Power

Large Image :  Dynamic Focusing System Computer To Screen With Optional 20W/25W Laser Power

Product Details:
Place of Origin: Suzhou, China
Brand Name: GIS
Certification: CE
Model Number: CTS1213V

Dynamic Focusing System Computer To Screen With Optional 20W/25W Laser Power

Description
Emulsion Thickness (EOM): Solvent Resistant Emulsion 3μm-150μm, Water Resistant Emulsion 3μm-350μm Focus System: Dynamic Focusing
Laser Type: UV Laser, Wavelength 405±5nm Min Screen Size ( Mm ): 400x250mm/ 15.8x9.8
Equipment Size (mm): 2000x1157.5x2247mm/ 78.7x45.6x88.5 Conditions: Yellow Light Room With Cleanliness, Temperature 22±2°C, 40-70% Relative Humidity (No Condensation)
File Format: 1_bit Tiff Etc. Screen Frame Thickness: 20-50mm (bespoke Service Is Available)
Highlight:

Dynamic Focusing CTS System

,

20W Computer To Screen System

,

PCB Computer To Screen

Dynamic Focusing System Computer To Screen With Optional 20W/25W Laser Power

Product Description:

CTS (Computer To Screen) is a powerful machine for direct printing of designs onto screens for the textile printing industry. It is equipped with Single Phase 110V/ 220V, 50/60HZ, 4KW, Compressor Air 0.5mpa, 1100x1200mm, 1270dpi/2540dpi, 1200x1300mm, and DMD DLP Technology, making it a reliable and efficient machine for screen printing. It is accurate and efficient in printing on screens, making it the perfect choice for the textile printing industry. With its advanced technology, it is capable of printing highly detailed designs with clarity and precision. It is also easy to use and fast, saving you time and money. CTS is the perfect choice for the textile printing industry, providing a reliable and efficient machine for screen printing.



Features:

  • Product Name: CTS Computer To Screen
  • Direct to-screen imaging system with UV laser
  • File format: 1_bit Tiff, etc.
  • Solvent Resistant Emulsion 3μm-150μm
  • Water Resistant Emulsion 3μm-350μm
  • UV laser curing
  • Yellow Light Room With Cleanliness
  • Temperature 22±2°C
  • 40-70% Relative Humidity (No Condensation)
  • Imaging System: DMD DLP Technology
  • Laser power: 20W/25W(Optional)
  • Exposure time: Adjustable


Technical Parameters:

Parameter Description
CTS Computer to Screen printing system for textile
Focus system Dynamic Focusing
Laser power 20W/25W(Optional)
Equipment size (mm) 2000x1157.5x2247mm/ 78.7x45.6x88.5
Application Textile, Decal, Label, Decoration, Packaging And PCB Etc.
File format 1_bit Tiff Etc.
Screen frame thickness 20-50mm (bespoke Service Is Available)
Exposure time 120-240s/㎡, #350 Yellow Mesh
Max exposure size (mm) 1100(Height)x1200(length)
Resolution 1270dpi/2540dpi(Optional)
Equipment net weight 1450KG


Applications:

Computer To Screen (CTS) is a direct to-screen imaging system developed by GIS, which is based on the advanced DMD DLP technology and Dynamic Focusing system. GIS CTS1213V is an ideal choice for the printing and engraving industry, especially for the textile, decal, label, decoration, packaging and PCB applications. It adopts single phase 110V/ 220V, 50/60HZ, 4KW, compressor air 0.5mpa power and supports various file formats like 1_bit Tiff etc. The CTS1213V is a Direct Laser Image & Exposure machine that offers fast imaging and exposure process with precise and clear output. It increases the efficiency and accuracy of the entire printing process and creates vibrant and beautiful printed graphics.



Customization:

Customized Service of GIS CTS1213V Computer To Screen

GIS CTS1213V Computer To Screen is a professional solution for textile, decal, label, decoration, packaging and PCB industries. It adopts 2540 dpi DMD technology and UV curing system, providing high-precision image processing and quick exposure time, which makes it suitable for precise and delicate patterns.

The product provides customized service for different needs. It is designed for a yellow light room with cleanliness, temperature 22±2°C and 40-70% relative humidity (no condensation). The frame thickness can be adjusted to 20-50mm and the size of the equipment is 2000x1157.5x2247mm/78.7x45.6x88.5. The exposure time is 120-240s/㎡, #350 yellow mesh.



Support and Services:

CTS Computer To Screen Technical Support and Service

CTS Computer To Screen provides the best in technical support and services for our customers. We have a team of highly experienced and knowledgeable professionals that can help you with any technical issue you may have with your CTS Computer To Screen product.

We offer a range of services from basic troubleshooting, to system installation and setup, to hardware repair and maintenance. We also provide comprehensive technical support and customer service for all CTS Computer To Screen products. Our team is available 24/7 to answer any questions or concerns you may have.

We also provide free software updates and upgrades to help keep your CTS Computer To Screen product up-to-date and running smoothly. We also offer extended warranties and product replacement services to ensure your CTS Computer To Screen product is always functioning properly.

At CTS Computer To Screen, we are committed to providing the best technical support and service for our customers. We strive to make sure that all of our customers are satisfied with their CTS Computer To Screen product and that their experience with us is as smooth as possible.



Packing and Shipping:

CTS Computer To Screen is a product that is carefully packaged and shipped for safe delivery. All orders are shipped with a tracking number and insurance to ensure that your product arrives in the same condition as it was shipped in.

CTS Computer To Screen is packaged in a sturdy box for safe delivery. Inside the box, the product is well-protected with foam-lined packaging. The box is then sealed with packing tape and labeled with the order details.

The product is then shipped via a reliable shipping carrier. The shipping carrier will provide a tracking number for the shipment so that you can follow your package and know when it is expected to arrive.



FAQ:

Q: What is CTS Computer To Screen?
A: CTS Computer To Screen is a product from GIS, Model Number CTS1213V, which is made in Suzhou, China. It is a computer-controlled screen printing machine that enables the direct output of images from a computer to a screen.
Q: What are the advantages of CTS Computer To Screen?
A: The advantages of CTS Computer To Screen include increased productivity, precision and accuracy, cost savings through reduced material waste, and improved print quality.
Q: What types of materials can be printed with CTS Computer To Screen?
A: CTS Computer To Screen can print on a variety of materials, including paper, film, fabric, and wood.
Q: What is the size of the printing area?
A: The printing area of CTS Computer To Screen is up to 600mm x 600mm.
Q: What is the maximum printing speed?
A: The maximum printing speed of CTS Computer To Screen is up to 1000 sheets per hour.
