Jiangsu GIS Laser Technologies Inc., fannie.tian@gis-group.com.cn 86--13625276829
Product Details
Place of Origin: Suzhou, China
Brand Name: GIS
Model Number: CTS1213V
Payment & Shipping Terms
Screen Frame Thickness: |
20-50mm (bespoke Service Is Available) |
Laser Power: |
20W/25W(Optional) |
Max Screen Size ( Mm ): |
1200(Height)x1300(length) |
Equipment Net Weight: |
1450KG |
Imaging System: |
DMD DLP Technology |
Max Exposure Size ( Mm ): |
1100(Height)x1200(length) |
Exposure Time: |
120-240s/㎡, #350 Yellow Mesh |
Laser Type: |
UV Laser, Wavelength 405±5nm |
Screen Frame Thickness: |
20-50mm (bespoke Service Is Available) |
Laser Power: |
20W/25W(Optional) |
Max Screen Size ( Mm ): |
1200(Height)x1300(length) |
Equipment Net Weight: |
1450KG |
Imaging System: |
DMD DLP Technology |
Max Exposure Size ( Mm ): |
1100(Height)x1200(length) |
Exposure Time: |
120-240s/㎡, #350 Yellow Mesh |
Laser Type: |
UV Laser, Wavelength 405±5nm |
CTS Computer To Screen is a revolutionary product that combines cutting-edge technology and innovative design to provide the ultimate solution for screen printing on textiles. This powerful equipment is designed to meet the demands of modern textile printing, providing high quality and efficient results in a compact and user-friendly design.
CTS Computer To Screen operates on a single phase power supply of 110V/220V, 50/60HZ, with a power consumption of 4KW. The compressor air pressure is 0.5mpa, ensuring stable and reliable performance during the printing process.
The exposure time of CTS Computer To Screen is between 120-240 seconds per square meter, making it one of the fastest in the market. It is compatible with #350 yellow mesh, providing optimal results for screen printing on textiles.
The maximum exposure size of CTS Computer To Screen is 1100mm in height and 1200mm in length, making it suitable for a wide range of textile printing applications. This large exposure size allows for greater flexibility and efficiency in the printing process.
CTS Computer To Screen uses a state-of-the-art UV laser with a wavelength of 405±5nm. This UV laser technology ensures precise and accurate imaging, resulting in high resolution and high-quality prints.
The imaging system of CTS Computer To Screen is based on DMD DLP technology, which provides advanced digital imaging capabilities. This technology allows for faster and more accurate image processing, resulting in superior quality prints.
CTS Computer To Screen is a game-changing product for the textile screen printing industry. With its advanced technology and user-friendly design, it provides high-quality and efficient results for a wide range of printing applications. Upgrade your printing process with CTS Computer To Screen and experience the future of textile screen printing.
Brand Name: GIS
Model Number: CTS1213V
Place of Origin: Suzhou, China
Power: Single Phase 110V/ 220V, 50/60HZ, 4KW, Compressor Air 0.5mpa
Max Exposure Size (mm): 1100 (Height) x 1200 (Length)
Equipment Net Weight: 1450KG
Min Screen Size (mm): 400x250mm/ 15.8x9.8
Application: Textile, Decal, Label, Decoration, Packaging and PCB, etc.
Are you tired of traditional screen printing methods that are time-consuming and produce low-quality results? Look no further than CTS Computer To Screen! Our revolutionary direct-to-screen imaging system is designed to make screen printing easier, faster, and more efficient.
Whether you're in the textile industry, creating decals, labels, decorations, or packaging, or in the PCB industry, CTS Computer To Screen is the perfect solution for all your screen printing needs. Our system can handle a variety of materials, including fabric, paper, plastic, and more.
Don't settle for mediocre results with traditional screen printing methods. Upgrade to CTS Computer To Screen and experience the difference in quality and efficiency. Contact us today to learn more and to schedule a demo!
Welcome to the world of high precision and high speed direct to-screen imaging system – GIS CTS1213V. Our customizable service allows you to tailor this product according to your specific needs and requirements.
Brand Name: GIS
Model Number: CTS1213V
Place of Origin: Suzhou, China
Laser type: UV Laser, Wavelength 405±5nm
Exposure time: 120-240s/㎡, #350 Yellow Mesh
File format: 1_bit Tiff Etc.
Laser power: 20W/25W(Optional)
Max screen size (mm): 1200(Height)x1300(length)
Our computer to-screen imaging system is equipped with a UV laser, with a wavelength of 405±5nm, providing high precision and accurate imaging results. The exposure time can be adjusted between 120-240 seconds per square meter, using #350 Yellow Mesh to ensure maximum efficiency.
The file format for this product is 1_bit Tiff Etc., making it compatible with various software and design programs. As for laser power, we offer the option of 20W or 25W, depending on your specific needs and preferences.
With a maximum screen size of 1200mm in height and 1300mm in length, our CTS1213V is capable of handling large designs and providing high quality output.
Our customization service focuses on providing you with the best experience and results. We use a 133 LPI raster for our imaging system, ensuring high resolution and accuracy. Our CTS1213V also has a high speed imaging capability, making it an ideal choice for time-sensitive projects.
Choose GIS CTS1213V for a customizable and reliable computer to-screen imaging system.
